28–54W (2700–5000lm) | 120V–277V | HK LED, RGBW, Amber
ZXL38-I Surface Mount
28–54W (2700–5000lm) | 120V–277V | HK LED, RGBW, Amber
Versatile line voltage surface mount LED accent light for commercial and large residential environments."
(includes former ZXL38i-GM-ADJ model)
FEATURES:
- 28W, 42W, 54W integrated HK LED delivering 2700–5000 lumens.
- Wet Location Listed, IP65 Standard.
- Machined from solid aircraft grade (6061-T6), corrosion-resistant aluminum, then anodized and powder coated to create a highly durable, marine grade finish. Also available in solid brass or stainless steel.
- Surface mount with fully adjustable aiming, 360º rotation and 15º tilting.
- Modular components, field changeable LED optical beams, and lenses.
- Every fixture tested end of line for water tightness and light quality.
- Ships complete with selected accessories installed.
Materials
Solid billet 6061-T6 corrosion-resistant aluminum with 304 stainless steel hardware. Available in 304/316 stainless steel or 360 brass upon request.
Voltage
120V–277V AC.
Optics
Narrow (16º), Medium (26º), Wide (60º) beam spread options available. Accepts up to 3 optical accessories (hexcel louver, optical lenses, dichroic color filters, etc.) Secured in place with metal snap ring.
Finish
Aluminum materials are first anodized and then powder coated for a robust, marine grade finish. Stainless steel and brass models are provided with brushed surface.
Wattage
28W, 42W, 54W HK LED delivering 2700–5000 lumens.
Mounting
Mounts with 3⁄8"-16 NPS Anchor Bolt.
Light Engine
Innovative HK LED Light module operates like a lamp and can be easily changed in the field. CRI 90 Standard. Available in CRI 80 or CRI 95 upon request. Standard CCT options are 2700K, 3000K, 3500K, 4000K. Specialty 2200K, 2400K, 2500K, Amber, and RGBW options available. Consult factory for specialty LED specification details.
Listings
ETL Listed for Wet Location, IP65 Standard. RoHS Compliant.
Dimming
Onboard, Integrated LED Driver, Phase Control @120V, 0V–10V @120V–277V, DALI or DMX control available, consult factory for details.
