ZFL16-I

FLOOD & WALL WASH | ZFL16 Series | 2.25" dia.
4–8W ( 250–500lm ) | 120V–277V | HK LED

ZFL16-I

FLOOD & WALL WASH | ZFL16 Series | 2.25" dia.
4–8W ( 250–500lm ) | 120V–277V | HK LED

(includes former ZXLFi model)

Strong 120V-277V LED round flood light for wall wash, landscape, hardscape, and signage illumination.

FEATURES:

4W, 8W integrated HK LED delivering 250–500 lumens per light. 2700–4000K CCT.
Wet Location Listed, IP67 Standard.
Machined from solid aircraft grade (6061-T6), corrosion-resistant aluminum, then anodized and powder coated to create a highly durable, marine grade finish. Also available in solid brass or stainless steel.
360° vertical and 360° horizontal adjustment via unique swivel stem design.
Available ground, surface, and canopy mounting options.
Every fixture tested end of line for water tightness and light quality.
Readymade eligible configurations ship in 2 to 4 weeks, complete with selected accessories installed.

spec sheets

installation

photometry

Specifications

Materials

Solid billet 6061-T6 corrosion-resistant aluminum with 316 stainless steel hardware.

Voltage

Universal 120V–277V AC with integral LED driver.

Optics

Includes Solite Soft Focus lens for smooth, even distribution of light.

Finish

Polyester powder coat on all aluminum materials with RoHS compliant procedures. Anodized finish is available. Stainless steel and brass models are provided with brushed surface.

Wattage

4 or 8W HK LED delivering 250–500 lumens.

Mounting

Mounts using 1/2"-14 NPS male fitting compatible with all HK Lighting mounting accessories. (See page 4 of the spec sheet for details)

Optional Barn Door

Optional barn doors for glare control and precision cut off. (See page 4 of the spec sheet for details)

Light Engine

Innovative HK LED light engine. CRI 90 Standard. Available in CRI 80 or CRI 95 upon request. Standard CCT options are 2700K, 3000K, 3500K, 4000K. Amber option available. Consult factory for specialty LED specification details.
