ZP16
PATH & BOLLARD | ZP16 Series | 2.25"
7.5W (640lm) | 12V | SORAA, LED Lamp, Halogen
7.5W (640lm) | 12V | SORAA, LED Lamp, Halogen
ZP16
PATH & BOLLARD | ZP16 Series | 2.25"
7.5W (640lm) | 12V | SORAA, LED Lamp, Halogen
7.5W (640lm) | 12V | SORAA, LED Lamp, Halogen
Versatile directional 12V MR16 (GU5.3) path light for residential and commercial environments.
(includes former PATH-1-SOi & PATH-2-SOi models)
FEATURES:
- Flexible lamp configurations include SORAA LED Lamp with patented Heat Sink or use your preferred LED or Halogen lamp.
- Wet Location Listed, IP67 Standard.
- Machined from solid aircraft grade (6061-T6), corrosion-resistant aluminum, then anodized and powder coated to create a highly durable, marine grade finish. Also available in solid brass or stainless steel.
- 240º vertical and 360º horizontal light adjustment via locking swivel stem design.
- Modular components, field changeable LED optical beams, and lenses.
- Available with adjustable Angled, Long, and Short Glare Shields and ground, surface.
- Single and double light mounting options at 12″, 24″, 30″ or custom height.
- Every fixture tested end of line for water tightness and light quality.
- Readymade eligible configurations ship in 2 to 4 weeks, complete with selected accessories installed.
Specifications
Materials
Solid billet 6061-T6 corrosion resistant aluminum with 304 stainless steel hardware.
Finish
Aluminum materials are first anodized and then powder coated for a robust, marine grade finish. Stainless steel and brass models are provided with brushed surface.
Hood and Glare Shield
Weeping and Non-weeping Hood Styles. Set screw or threaded Angled, Short, or Long Glare Shields. (See page 4 of Spec Sheet for details).
Voltage
12V AC/DC. Requires remote step down transformer.
Wattage
Max 9W for SORAA MR16 lamp with Thermobuster. Max 50W for halogen lamp.
Light Engine
MR16 Halogen lamp or MR16 SORAA® LED lamp. Please refer to SORAA MR16 GU5.3 lamp selection.
Dimming
MLV, ELV Phase Control dimming. Please refer to SORAA website for SORAA® MR16 dimmer compatibility.
Lamp Base/Socket
Standard bi-pin socket for GU5.3/G4/ GX5.3/GY6.35/GZ4.
Optics
Accepts up to 3 accessories (hexcel louver, optical lenses, dichroic color filters, etc.). Secured in place with metal snap ring.
Mounting
Mounts using 1/2"-14 NPS male fitting compatible with all HK Lighting Group mounting devices. (See page 4 of Spec Sheet for details).
Listings
ETL Listed for Wet Location, IP67 Standard. RoHS Compliant.
