ZX16-IP-GU10
Image Projector • ZX16-IP Series
ZX16-IP-GU10
Image Projector • ZX16-IP Series
GU10 SORAA® LED image projector
FEATURES:
- Small Image projector using GOBO, color filter or colorizer for outdoor or indoor application.
- ETL outdoor wet location listed. IP65 standard.
- Machined from solid billet 6061-T6 corrosion resistant aluminum.
- 240° vertical and 360° horizontal adjustment via unique swivel stem design.
- US patented integral SORAA heat sink.
- Line voltage input using GU10 base MR16 lamp.
Specifications
Materials
Machined from billet 6061-T6 corrosion resistant aluminum with 304 stainless steel hardware. Available in 304/316 stainless steel or 360 brass upon request.
Voltage
120V or 230V AC.
Lamp Base/Socket
Porcelain GU10 twist - lock lamp base.
Finish
Polyester powder coat on all aluminum materials with RoHS compliant procedures. Anodized finish is available. Stainless steel and brass models are provided with brushed surface.
Wattage
Max. 9W for SORAA MR16 lamp with Thermobuster. Max. 50W for halogen MR16 without Thermobuster.
Optics
Accepts combinations of accessories (including colorizer, color filters, steel gobo etc.). Secured in place with metal snap ring.
Glare Shield
3 optional glare shields(GSL-long, GSA-angled, GSS-short) for additional glare control. (See page 3 of Spec Sheet for details).
Light Engine
MR16 GU10 Halogen lamp or MR16 GU10 SORAA LED lamp.
Mounting
Mounts using 1/2"-14 NPS male fitting compatible with all HK Lighting Group mounting devices.
Dimming
Phase.
GOBO Size
(See data on second page of Spec Sheet).
Compatible Accessories
